2005-2006 BUICK ALLURE 3.6L 217CID V6 DOHC, (12 VALVE), VIN CODE "7"
2005-2006 BUICK LACROSSE 3.6L 217CID V6 DOHC, (12 VALVE), VIN CODE "7"
2004-2006 BUICK RENDEZVOUS 3.6L 217CID V6 DOHC, (12 VALVE), VIN CODE "7"
2004-2006 CADILLAC CTS 3.6L 217CID V6 DOHC, (12 VALVE), VIN CODE "7"
2004-2006 CADILLAC SRX 3.6L 217CID V6 DOHC, (12 VALVE), VIN CODE "7"
2005-2006 CADILLAC STS 3.6L 217CID V6 DOHC, (12 VALVE), VIN CODE "7"
This item includes:
Full Gasket Set (Multiple Layers Steel (MLS) Head Gasket, Valve Cover Gasket, Valve Stem Seals, Intake Manifold Gasket, ..., Other Small Gaskets, RTV Silicone)
18 Cylinder Head Bolts (16 Long Bolts, 2 Short Bolts)
6 Pistons with Complete Ring Set (sizes available: see options above)
Standard Bore Diameter: 94.00mm
1st Group: 1.20mm
2nd Group: 1.50mm
Oil Ring: 2.50mm
6 Piston Wrist Pins
12 Cir Clips
Main Bearing Set (sizes available: see options above)
Rod Bearing Set (sizes available: see options above)
1 Timing Chain lower (primary silent 78 link)
2 Timing Chain upper (secondary 92 link - roller type)
1 Tensioner lower (primary - crank to idlers)
1 Tensioner secondary (right side upper)
1 Tensioner secondary (left side upper)
2 Cam Sprocket (intake VVT 32 teeth) - are not included
2 Cam Sprocket (exhaust VVT 32 teeth) - are not included
1 Idler Sprocket (right combo 18T / 27T)
1 Idler Sprocket (left combo 18T / 27T)
1 Crank Sprocket (24 teeth non roller style)
1 Guide Rail lower (primary right side fixed)
1 Guide Rail lower (primary upper / fixed)
1 Guide Rail left upper (secondary tensioner rail)
1 Guide Rail right upper (secondary tensioner rail)
1 Guide Rail left upper (secondary fixed rail)
1 Guide rail right upper (secondary fixed rail)
1 Water Pump w/ Gasket
1 Oil Pump
